Snack Processing Machine

Potato french fries production line 100kg per hour

  • Capcity: 100kg/hour
  • Power:
  • Voltage:
  • Ports: Qing Dao,Ning Bo
  • Size:
  • Payment: T/T,Western Union L/C

Send an E-mail to us!

(※ Click this button to inquiry)

  • Frozen Potato Chips Production Line
■ Application and Features

Introduction of Frozen Potato Chips Production Line

hoisting and feeding ----- washing and peeling----- selecting-----hoisting and feeding-----cutting into slices or sticks----- rinsing -----blanching and color protection----- removing water----- frying ---- de-oiling----- freezing (FROZEN STICKS ) or seasoning ( POTATO SLICES)-----conveying -----packaging
1) The french fries production line is made up of stainless steel, durable and healthy.
2) According to your capacity we have semi-automatic and fully automatic processing line for your choice.
3) Apart from using potato as material, you could also use other food as well, such as sweet potato, carrot ,banana chips and other kinds of taros.
4) Multipurpose cutting machine, able to cut potatoes to slice or bar shape, and you could adjust the thickness and size of them.
5) Advanced frying machine, highly increasing the using life of oil, saving energy.With Pure oil filtration process, use less oil, to improve the rate of replacement of oil.6). This equipment has automatic discharge, automatic mixing, and automatic temperature control function Note: The power source could use Electric, Coal, Diesel oil, natural Gas and Conductive-oil etc .and the special sizes could customize based on the demands of user.

No.

Goods

Specifications

01

Washing machine



Power: 1.1kw

Size:(m)1.4×1.0×2.2

Weight of machine: 200Kg

02

Peeling machine



Power: 3.5kw

Size:(m)1.8×1.0×1.0

Weight of machine: 200Kg

03

Work table(2sets)



Power: 1.1kw

Size:(m)2.6×0.8×1.1

Weight of machine: 100Kg

04

Conveyer(2sets)





Power: 0.37kw

Size:(m)2.0×0.4×21.0

Weight of machine: 180Kg

05

Cutter



Power: 1.5kw

Size:(m)0.9×0.7×1.0

Weight of machine: 300Kg

06

Washing



Power: 0.8kw

Size:(m)2.8×0.8×1.2

Weight of machine: 300Kg

07

Blanching



Power: 1.2kw

Size:(m)5.4×1.0×1.45

Weight of machine: 750Kg

08

Fryer



Power: 0.37kW+0.55kW

Size:(m)8.0×1.0×1.6

Weight of machine: 700Kg



Waste remove machine



Size:(m) 0.9×0.5×1.0

Weight of machine: 100Kg



Oil tank



Volume: 1.0CBM

Size:(m)1.2×3.0

Weight of machine: 200Kg

Including the steam heating tube and valve

09

Flavoring machine



Power: 0.37kW+250W

Size:(m)1.75×1.2×1.5

Weight of machine: 300Kg



■ Specifications

Potato french fries production line 100kg per hour
