Snack Processing Machine
Potato french fries production line 100kg per hour
- Capcity: 100kg/hour
- Power:
- Voltage:
- Ports: Qing Dao,Ning Bo
- Size:
- Payment: T/T,Western Union L/C
(※ Click this button to inquiry)
Introduction of Frozen Potato Chips Production Line
hoisting and feeding ----- washing and peeling----- selecting-----hoisting and feeding-----cutting into slices or sticks----- rinsing -----blanching and color protection----- removing water----- frying ---- de-oiling----- freezing (FROZEN STICKS ) or seasoning ( POTATO SLICES)-----conveying -----packaging
1) The french fries production line is made up of stainless steel, durable and healthy.
2) According to your capacity we have semi-automatic and fully automatic processing line for your choice.
3) Apart from using potato as material, you could also use other food as well, such as sweet potato, carrot ,banana chips and other kinds of taros.
4) Multipurpose cutting machine, able to cut potatoes to slice or bar shape, and you could adjust the thickness and size of them.
5) Advanced frying machine, highly increasing the using life of oil, saving energy.With Pure oil filtration process, use less oil, to improve the rate of replacement of oil.6). This equipment has automatic discharge, automatic mixing, and automatic temperature control function Note: The power source could use Electric, Coal, Diesel oil, natural Gas and Conductive-oil etc .and the special sizes could customize based on the demands of user.
No. |
Goods |
Specifications |
01 |
Washing machine
|
Power: 1.1kw Size:(m)1.4×1.0×2.2 Weight of machine: 200Kg |
02 |
Peeling machine
|
Power: 3.5kw Size:(m)1.8×1.0×1.0 Weight of machine: 200Kg |
03 |
Work table(2sets)
|
Power: 1.1kw Size:(m)2.6×0.8×1.1 Weight of machine: 100Kg |
04 |
Conveyer(2sets)
|
Power: 0.37kw Size:(m)2.0×0.4×21.0 Weight of machine: 180Kg |
05 |
Cutter
|
Power: 1.5kw Size:(m)0.9×0.7×1.0 Weight of machine: 300Kg |
06 |
Washing
|
Power: 0.8kw Size:(m)2.8×0.8×1.2 Weight of machine: 300Kg |
07 |
Blanching
|
Power: 1.2kw Size:(m)5.4×1.0×1.45 Weight of machine: 750Kg |
08 |
Fryer
|
Power: 0.37kW+0.55kW Size:(m)8.0×1.0×1.6 Weight of machine: 700Kg |
|
Waste remove machine
|
Size:(m) 0.9×0.5×1.0 Weight of machine: 100Kg |
|
Oil tank
|
Volume: 1.0CBM Size:(m)1.2×3.0 Weight of machine: 200Kg Including the steam heating tube and valve |
09 |
Flavoring machine
|
Power: 0.37kW+250W Size:(m)1.75×1.2×1.5 Weight of machine: 300Kg |
Potato french fries production line 100kg per hour
Please enter your demand such as Raw material type,Capacity, Feeding material size, Final product size. We will reply you as soon as possible.
