The heat pump dryer machine applies a compressor to suck low-temperature and low-pressure
refrigerant gas from the evaporator, and compresses the refrigerant into high temperature and
high-pressure gas through work, and the high-temperature and high-pressure gas enters the condenser
and exchanges heat with the air through the action of the fan, and is condensed in the condenser. The
low temperature liquid releases a large amount of heat, and the air absorbs the heat and the
temperature rises. Then the high-pressure low-temperature liquid is throttled and depressurized by the
expansion valve, the heat of the surrounding air is dissipated into a low-pressure gas by the action of
the fan in the evaporator. And is sucked into the compressor for compression, so that the cycle is
repeated, thereby continuously increasing the temperature of the drying room.
Machine Feature:
◆ Efficient and energy saving: The heat pump dryer machine obtains a large amount of free heat from
the air, and the power consumed is the energy required for the compressor to carry air and sunlight
energy only.
Therefore, the same amount of drying is provided, and the amount of electricity used is reduced greatly,
which saves a large amount of electricity consumption.
◆ Green and environmental protection: The dryer use clean energy from electricity and atmospheric
ambient air, and does not use environmental pollution caused by fossil fuels such as oil, coal and gas. It
does not emit harmful gases during work, saving energy and protecting the environment greatly.
◆ All-weather use: The indoor use of the dryer is not affected by bad weather such as cloudy and rain,
and can be used all day continuously..
◆ Long-lasting durability: The main parts such as compressors and four way
valves used in this heat pump dryer machine are made of high-quality products
produced by world-famous factories. The outer casing is made of corrosion resistant
stainless steel plates, which guarantees the quality of the dryer
and also increases the service life greatly.
◆ Wide range of applications: This dryer can be use to dry various kinds of materials with different
capacities, and also has sterilizing, heating functions
, Model: ZLHP-1.5P (loading capacity 150~200kg/batch)
1, Drying temperature: 18~80℃(we will install PTC heater on the machine if customer need temp.
higher than 80℃)
2, Humidity setting range: 5~99%
3, Working mode: open style/closed style/fixed temperature/floating temperature
4, Dehumidification rate: 4.5L water/h(heat pump dehumidification capacity only)
5, Drying chamber: LxWxH=720X700X1810mm
6, Drying tray size: LxWxH=710X680x20mm, hole tray, total 18 pcs
7, Bottom collection tray: LxWxH=710X680x20mm,plain tray(without hole),1 pc
8, Input power: 1.91Kw (heat pump only)
9, Rated input current: 9.6A
10, Rated voltage/frequency: 220V/50Hz
11, Aauxiliary electric heater power: 2Kw (will increase the power according to customer’s temp.
requirement)
12, Max. input power: less than 2.59Kw
13, Max. input current: 13.7A
14, Working ambient temperature: -10~40℃
15, Noise: less than 65dB
16, Overall dimension: 1270x760x1850
17, Net weight: 206kg
